SF-0603F100-2
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Circuit Protection / Fuses
Description
FUSE BOARD MOUNT 1A 32VDC 0603
PDF
/
Buying Options
Total Price: USD $0.58
Unit Price: USD $0.5808
≥1 USD $0.5808
≥10 USD $0.56144
≥100 USD $0.54384
≥500 USD $0.4576
≥1000 USD $0.379896
≥3000 USD $0.345347
Inventory: 1260
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Terminal Shape WRAPAROUND
Number of Pins 2
Body Material Ceramic
Terminal Material Copper
Technical
Operating Temperature -20°C~105°C
Packaging Tape & Reel (TR)
Published 2008
Series SinglFuse? SF-0603F
Size / Dimension 0.063Lx0.032W x 0.018 H 1.60mmx0.80mmx0.45mm
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Resistance 88mOhm
Terminal Finish Tin (Sn)
Voltage - Rated 32V
HTS Code 8536.10.00.40
Voltage - Rated DC 32V
Packing Method TAPE AND REEL
Depth 800μm
Current Rating 1A
Base Part Number SF-0603
Reference Standard UL
Case Code (Metric) 1608
Approval Agency UL
Body Length or Diameter 1.6mm
Case Code (Imperial) 0603
Body Breadth 0.8 mm
Physical Dimension 1.6mm x 0.8mm x 0.45mm
Max Voltage Rating (DC) 32V
Response Time Fast Blow
Fuse Type Board Mount (Cartridge Style Excluded)
Breaking Capacity @ Rated Voltage 50A
Melting I2t 0.016
DC Cold Resistance 0.088Ohm
Circuit Protection Type ELECTRIC FUSE
Fuse Current 1A
Dimensions
Height 450μm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
