5SF 5
RoHS
/
Package 5mm x 20mm
Category Circuit Protection / Fuses
Description
FUSE GLASS 5A 250VAC 5X20MM
PDF
/
Inventory: 9089
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Holder
Package / Case 5mm x 20mm
Surface Mount NO
Terminal Shape END CAP
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series 5SF
Size / Dimension 0.201Diax0.787L 5.10mmx20.00mm
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Current Rating (Amps) 5A
Reference Standard CCC; CE; CSA; SEMKO; UL; VDE
Voltage - Rated AC 250V
Approval Agency CE, CSA, IMQ, SEMKO, UL, VDE
Body Length or Diameter 5.1mm
Physical Dimension 5.1mm x 20mm
Response Time Fast Blow
Fuse Type Cartridge, Glass
Breaking Capacity @ Rated Voltage 50A
Rated Current 5A
Melting I2t 41
DC Cold Resistance 0.014Ohm
Circuit Protection Type ELECTRIC FUSE
Fuse Size 5x20mm
Joule Integral-Nom 41 J
Dimensions
Body Height 20mm
Compliance
RoHS Status Non-RoHS Compliant
