5MF 8-R
RoHS
RoHS compliant
RoHS compliantPackage 5mm x 20mm
Category Circuit Protection / Fuses
Description
FUSE GLASS 8A 125VAC 5X20MM
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.5368
≥1 USD $0.5368
≥10 USD $0.50424
≥100 USD $0.352
≥500 USD $0.239976
≥1000 USD $0.215978
≥3000 USD $0.207979
Inventory: 1110
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Holder
Package / Case 5mm x 20mm
Surface Mount NO
Terminal Shape END CAP
Technical
Operating Temperature -55°C~125°C
Packaging Bulk
Series 5MF
Size / Dimension 0.201Diax0.787L 5.10mmx20.00mm
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Additional Feature PRE-ARCING TIME: OPEN WITHIN 5 SEC. AT 200% RATED CURRENT
Current Rating (Amps) 8A
Reference Standard CE; CSA; PSE
Voltage - Rated AC 125V
Approval Agency CE, CSA, cULus, PSE
Body Length or Diameter 5.1mm
Physical Dimension 5.1mm x 20mm
Response Time Fast Blow
Fuse Type Cartridge, Glass
Breaking Capacity @ Rated Voltage 10kA
Rated Current 8A
Melting I2t 113
DC Cold Resistance 0.009Ohm
Circuit Protection Type ELECTRIC FUSE
Fuse Size 5x20mm
Joule Integral-Nom 113 J
Dimensions
Body Height 20mm
Compliance
RoHS Status ROHS3 Compliant
