3JS 200-R
RoHS
RoHS compliant
RoHS compliantPackage 2AG, 5mm x 15mm (Axial)
Category Circuit Protection / Fuses
Description
FUSE GLASS 200MA 350VAC 140VDC
PDF
/
Inventory: 5952
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Body Height 18mm
Technical
Fuse Size 5x15mm
Blow Characteristic TIME LAG
Circuit Protection Type ELECTRIC FUSE
DC Cold Resistance 3.5Ohm
Melting I2t 0.26
Rated Current 0.2A
Breaking Capacity @ Rated Voltage 100A AC 150A DC
Fuse Type Cartridge, Glass
Response Time Slow Blow
Physical Dimension 6.2mm x 18mm
Body Length or Diameter 6.2mm
Approval Agency CE, CSA, cURus
Voltage - Rated AC 350V
Reference Standard CE; CSA; UL
Current Rating (Amps) 200mA
Voltage - Rated DC 140V
HTS Code 8536.10.00.40
Additional Feature PRE-ARCING TIME: OPEN WITHIN 30 MILLISEC. AT 1000% RATED CURRENT; RATED BREAKING CAPACITY AT 140 VDC: 150 A
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Part Status Last Time Buy
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 0.217Diax0.591L 5.50mmx15.00mm
Series 3JS
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Terminal Shape PIN WIRE
Surface Mount NO
Package / Case 2AG, 5mm x 15mm (Axial)
Mounting Type Through Hole
