0082263019
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Flat Ribbon Cables
Description
19 24463 Gray Poly-Vinyl Chloride (PVC) Flat Ribbon Cable 100.0' 30.48m 26AWG 300V -20C~105C
PDF
/
Inventory: 3793
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Conductor Material Copper, Topcoat
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Technical
Operating Temperature -20°C~105°C
Series 24463
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Pitch 0.079 2.00mm
Shielding Unshielded
Number of Conductors 19
Wire Gauge 26 AWG
Voltage 300V
Cable Type Flat Cable
Jacket Color Gray
Conductor Strand 19 Strands / 38 AWG
Ribbon Width 1.496 38.00mm
First Conductor Mark Blue
Dimensions
Length 100.0' 30.48m
Ribbon Thickness 0.041 1.04mm
Compliance
RoHS Status ROHS3 Compliant
Ratings UL E61522
