09180607006

HARTING
RoHS
RoHS RoHS compliant
Package 100
Category Cables, Wires / Flat Ribbon Cables
Description Flat Cables TWISTD PAIR FLAT CBL 60WIRE 100 FT/REEL
PDF
/
Inventory: 5311
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Ratings UL Style 20130
RoHS Status ROHS3 Compliant

Dimensions

Ribbon Thickness 0.042 1.07mm
Width 76.86mm
Length 100.0' 30.48m

Technical

Number of Pairs 30
First Conductor Mark Red
Number of Strands 7
Ribbon Width 3.026 76.86mm
Conductor Strand 7 Strands / 28 AWG
Jacket Color Multiple
Wire/Cable Gauge 28 AWG
Wire/Cable Type Flat
Cable Type Flat Cable
Insulation Resistance 100MOhm
Wire Gauge 28 AWG
Approval Agency UL
Number of Conductors 60 (30 Pair Twisted)
Current Rating 1A
Shielding Unshielded
Pitch 0.050 1.27mm
Capacitance 49pF
Voltage - Rated 300V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Operating Temperature -20°C~105°C

Physical

Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Conductor Material Copper, Tinned
Insulation Material PVC
Package / Case 100
Mount Cable

Supply Chain

Factory Lead Time 9 Weeks
