09180207008
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Flat Ribbon Cables
Description
Flat Cables SEK CAB FLAT NSH RND AWG28/7 20P 30,48M
PDF
/
Buying Options
Total Price: USD $363.24
Unit Price: USD $363.2376
≥1 USD $363.2376
≥10 USD $288.84064
≥100 USD $262.58144
≥500 USD $230.488544
Inventory: 65
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Ribbon Thickness 0.035 0.89mm
Width 25.4mm
Length 100.0' 30.48m
Technical
First Conductor Mark Red
Number of Strands 7
Ribbon Width 1.000 25.40mm
Conductor Strand 7 Strands / 28 AWG
Jacket Color Black
Wire/Cable Gauge 28 AWG
Wire/Cable Type Flat
Cable Type Flat Cable, Round Jacket
Insulation Resistance 100MOhm
Wire Gauge 28 AWG
Number of Conductors 20
Current Rating 2.1A
Shielding Unshielded
Pitch 0.050 1.27mm
Capacitance 78.7pF
Voltage - Rated 300V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Operating Temperature -20°C~105°C
Physical
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Conductor Material Copper, Tinned
Insulation Material PVC
Mount Cable
Supply Chain
Factory Lead Time 11 Weeks
