09180107008
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Flat Ribbon Cables
Description
Flat Cables SEK CAB FLAT NSH RND AWG28/7 10P 30,48M
PDF
/
Buying Options
Total Price: USD $2.71
Unit Price: USD $2.711553
≥1 USD $2.711553
≥10 USD $2.558075
≥100 USD $2.413273
≥500 USD $2.276669
≥1000 USD $2.147813
Inventory: 1674
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Cable
Insulation Material PVC
Conductor Material Copper, Tinned
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Technical
Operating Temperature -20°C~105°C
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated 300V
Capacitance 78.7pF
Pitch 0.050 1.27mm
Shielding Unshielded
Current Rating 1.3A
Number of Conductors 10
Wire Gauge 28 AWG
Insulation Resistance 100MOhm
Cable Type Flat Cable, Round Jacket
Wire/Cable Type Flat
Wire/Cable Gauge 28 AWG
Jacket Color Black
Conductor Strand 7 Strands / 28 AWG
Ribbon Width 0.500 12.70mm
Number of Strands 7
First Conductor Mark Red
Dimensions
Length 100.0' 30.48m
Width 12.78mm
Ribbon Thickness 0.035 0.89mm
Compliance
RoHS Status ROHS3 Compliant
