HF100/14TP

3M
RoHS
RoHS RoHS compliant
Package /
Category Cables, Wires / Flat Ribbon Cables
Description CABLE 14POS 28AWG STR .05" 100'
PDF
/
Buying Options
Total Price: USD $3.1
Unit Price: USD $3.096896
≥1 USD $3.096896
≥10 USD $2.731018
≥100 USD $2.469685
≥500 USD $2.234478
≥1000 USD $1.973136
Inventory: 220
Minimum: 1
-
+

Technical Details

Compliance

Ratings UL Style 21008
RoHS Status ROHS3 Compliant

Dimensions

Ribbon Thickness 0.070 1.78mm
Length 100.0' 30.48m

Technical

Ribbon Width 0.700 17.78mm
Conductor Strand 7 Strands / 36 AWG
Jacket Color Blue, White
Wire/Cable Gauge 28 AWG
Wire/Cable Type Flat
Cable Type Flat Twisted Pair
Voltage 150V
Insulation Resistance 10GOhm
Wire Gauge 28 AWG
Approval Agency UL
Number of Conductors 14 (7 Pair Twisted)
Shielding Unshielded
Pitch 0.050 1.27mm
Current Rating (Amps) 1A
Voltage - Rated 150V
Color Blue, White
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series HF100
Published 2012
Operating Temperature -40°C~105°C

Physical

Jacket (Insulation) Material Polyolefin (PO)
Conductor Material Copper, Tinned
Insulation Material PO

Supply Chain

Factory Lead Time 5 Weeks
