3749/16

3M
RoHS
/
Package 100
Category Cables, Wires / Flat Ribbon Cables
Description Flat Cables UL/16/CAB/TYP1/TPE RC/30G/SLD/.025/100
PDF
/
Buying Options
Total Price: USD $89.51
Unit Price: USD $89.5136
≥1 USD $89.5136
≥10 USD $71.41728
≥100 USD $64.63072
≥500 USD $56.875104
≥1000 USD $51.381616
≥3000 USD $46.85736
Inventory: 72
Minimum: 1
-
+

Technical Details

Compliance

Ratings UL Style 20297
RoHS Status RoHS Compliant
REACH SVHC Unknown

Dimensions

Ribbon Thickness 0.025 0.64mm
Length 100.0' 30.48m

Technical

First Conductor Mark Blue
Ribbon Width 0.402 10.20mm
Number of Cores 16
Conductor Strand Solid
Jacket Color Gray
Propagation Delay 1.48 ns
Wire/Cable Gauge 30 AWG
Wire/Cable Type Flat Flex
Impedance 90Ohm
Cable Type Flat Cable
Inductance 130 nH
Voltage 150V
Insulation Resistance 10GOhm
Wire Gauge 30 AWG
Number of Conductors 154 (77 Pair Twisted)
Shielding Unshielded
Pitch 0.025 0.64mm
Voltage - Rated DC 50V
Capacitance 16.5pF
Voltage - Rated 150V
Color Grey
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Zippable
Published 2013
Operating Temperature -40°C~105°C

Physical

Jacket (Insulation) Material Thermoplastic Elastomer (TPE)
Conductor Material Copper, Tinned
Weight 3.175147kg
Insulation Material TPE
Package / Case 100
Mount Cable

Supply Chain

Factory Lead Time 5 Weeks
