3539/34
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Flat Ribbon Cables
Description
CBL RIBN 34COND 0.050 GRAY 100'
PDF
/
Buying Options
Total Price: USD $4.06
Unit Price: USD $4.062113
≥1 USD $4.062113
Inventory: 9815
Minimum: 1
-
+
Technical Details
Compliance
Ratings UL Style 2651
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Ribbon Thickness 0.035 0.89mm
Length 100.0' 30.48m
Technical
First Conductor Mark Red
Ribbon Width 1.700 43.18mm
Number of Cores 34
Conductor Strand 19 Strands / 40 AWG
Jacket Color Gray
Wire/Cable Gauge 28 AWG
Wire/Cable Type Flat
Cable Type Flat Cable
Voltage 300V
Insulation Resistance 10GOhm
Wire Gauge 28 AWG
Number of Conductors 34
Depth 43.18mm
Shielding Unshielded
Pitch 0.050 1.27mm
Voltage - Rated DC 50V
Voltage - Rated 50V
Color Grey
Min Operating Temperature -20°C
Max Operating Temperature 105°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Zippable
Series 3539
Published 2003
Operating Temperature -20°C~105°C
Physical
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Conductor Material Copper, Tinned
Insulation Material PVC
Mount Cable
Supply Chain
Factory Lead Time 8 Weeks
