3365/25SF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cables, Wires / Flat Ribbon Cables
Description
Flat Cables 500SF 25/CAB/TYP1/ 28G/STR/.050/SF/500
PDF
/
Inventory: 8021
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings UL Style 2651
RoHS Status RoHS Compliant
Dimensions
Ribbon Thickness 0.035 0.89mm
Length 500.0' 152.40m
Technical
First Conductor Mark Red
Ribbon Width 1.250 31.75mm
Cable Pitch 1.27mm
Conductor Strand 7 Strands / 36 AWG
Jacket Color Gray
Cable Type Flat Cable
Voltage 300V
Insulation Resistance 10GOhm
Wire Gauge 28 AWG
Number of Conductors 25
Shielding Unshielded
Pitch 0.050 1.27mm
Color Grey, Red
Min Operating Temperature -20°C
Max Operating Temperature 105°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Zippable
Series 3365
Operating Temperature -20°C~105°C
Physical
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Conductor Material Copper, Tinned
Weight 7.937866kg
Mount Cable
Supply Chain
Factory Lead Time 5 Weeks
