2010/40 100SF
RoHS
/
Package /
Category Cables, Wires / Flat Ribbon Cables
Description
40 2010 White Polyolefin (PO) Flat Ribbon Cable 100.0' 30.48m 28AWG 10GOhm 30V
PDF
/
Inventory: 4790
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Conductor Material Copper, Tinned
Jacket (Insulation) Material Polyolefin (PO)
Technical
Operating Temperature -20°C~105°C
Published 2003
Series 2010
Feature Zippable
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Pitch 0.050 1.27mm
Shielding Unshielded
Number of Conductors 40
Wire Gauge 28 AWG
Insulation Resistance 10GOhm
Voltage 30V
Cable Type Flat Cable
Jacket Color White
Conductor Strand 7 Strands / 36 AWG
Ribbon Width 2.000 50.80mm
First Conductor Mark Blue
Dimensions
Length 100.0' 30.48m
Ribbon Thickness 0.035 0.89mm
Compliance
Ratings UL Style 20930
