784776147
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PD2A Nonstandard 0.394Lx0.354W 10.00mmx9.00mm 47muH
PDF
/
Buying Options
Total Price: USD $1.85
Unit Price: USD $1.84918
≥1 USD $1.84918
≥10 USD $1.744506
≥100 USD $1.645761
≥500 USD $1.552603
≥1000 USD $1.464719
Inventory: 1323
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package 1054
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-PD2A
Size / Dimension 0.394Lx0.354W 10.00mmx9.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 1.45A
Shielding Unshielded
Current Rating 1.45A
Inductance 47μH
Test Frequency 10kHz
DC Resistance (DCR) 170mOhm Max
Frequency - Self Resonant 11MHz
Inductance Frequency - Test 10kHz
Current - Saturation 1.62A
Dimensions
Height Seated (Max) 0.232 5.90mm
Length 10.0076mm
Width 8.9916mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
