784775233
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PD2A Nonstandard 0.307Lx0.276W 7.80mmx7.00mm 330muH
PDF
/
Inventory: 3121
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package 7850
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-PD2A
Size / Dimension 0.307Lx0.276W 7.80mmx7.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 430mA
Shielding Unshielded
Current Rating 430mA
Inductance 330μH
Test Frequency 10kHz
DC Resistance (DCR) 1.26Ohm Max
Frequency - Self Resonant 4MHz
Inductance Frequency - Test 10kHz
Current - Saturation 480mA
Dimensions
Height Seated (Max) 0.217 5.50mm
Length 7.7978mm
Width 7.0104mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
