784775122
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PD2A Nonstandard 0.307Lx0.276W 7.80mmx7.00mm 22muH
PDF
/
Buying Options
Total Price: USD $1.92
Unit Price: USD $1.924989
≥1 USD $1.924989
≥10 USD $1.816029
≥100 USD $1.713233
≥500 USD $1.616258
≥1000 USD $1.524776
Inventory: 1188
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Width 7.0104mm
Length 7.7978mm
Height Seated (Max) 0.217 5.50mm
Height 5.5mm
Technical
Ambient Temperature Range High 85°C
Series Resistance 110mOhm
RMS Current (Irms) 1.76A
Current - Saturation 1.81A
Inductance Frequency - Test 10kHz
Frequency - Self Resonant 15MHz
DC Resistance (DCR) 110mOhm Max
Test Frequency 10kHz
Inductance 22μH
Current Rating 1.76A
Shielding Unshielded
Current Rating (Amps) 1.76A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.307Lx0.276W 7.80mmx7.00mm
Series WE-PD2A
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Supplier Device Package 7850
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
