784771221
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PDA Nonstandard 0.472Lx0.472W 12.00mmx12.00mm 220muH
PDF
/
Inventory: 3689
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package 1260
Material - Core Nickel Zinc Ferrite (NiZn)
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-PDA
Size / Dimension 0.472Lx0.472W 12.00mmx12.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 990mA
Shielding Shielded
Current Rating 990mA
Inductance 220μH
Test Frequency 100kHz
DC Resistance (DCR) 348mOhm Max
Frequency - Self Resonant 3.9MHz
Inductance Frequency - Test 100kHz
Current - Saturation 1.1A
Dimensions
Height Seated (Max) 0.248 6.30mm
Length 11.9888mm
Width 11.9888mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
