784771220
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PDA Nonstandard 0.472Lx0.472W 12.00mmx12.00mm 22muH
PDF
/
Buying Options
Total Price: USD $1.98
Unit Price: USD $1.979717
≥1 USD $1.979717
≥10 USD $1.867661
≥100 USD $1.761941
≥500 USD $1.662206
≥1000 USD $1.568114
Inventory: 1129
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package 1260
Material - Core Nickel Zinc Ferrite (NiZn)
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-PDA
Size / Dimension 0.472Lx0.472W 12.00mmx12.00mm
Tolerance ±20%
Part Status Active
Current - Saturation 3.5A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 14.9MHz
DC Resistance (DCR) 40mOhm Max
Test Frequency 100kHz
Inductance 22μH
Current Rating 3.2A
Shielding Shielded
Current Rating (Amps) 3.2A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Width 11.9888mm
Length 11.9888mm
Height Seated (Max) 0.248 6.30mm
