7847709220
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PDA Nonstandard 0.472Lx0.472W 12.00mmx12.00mm 22muH
PDF
/
Buying Options
Total Price: USD $2.5
Unit Price: USD $2.498837
≥1 USD $2.498837
≥10 USD $2.3574
≥100 USD $2.22396
≥500 USD $2.098079
≥1000 USD $1.979312
Inventory: 5930
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package 1210
Material - Core Nickel Zinc Ferrite (NiZn)
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-PDA
Size / Dimension 0.472Lx0.472W 12.00mmx12.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 4.3A
Shielding Shielded
Current Rating 4.3A
Inductance 22μH
Test Frequency 100kHz
DC Resistance (DCR) 44mOhm Max
Frequency - Self Resonant 11MHz
Inductance Frequency - Test 100kHz
Current - Saturation 5A
Dimensions
Height Seated (Max) 0.406 10.30mm
Length 11.9888mm
Width 11.9888mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
