784383230047
RoHS
RoHS compliant
RoHS compliantPackage 1008 (2520 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-MAIA 1008 (2520Metric) 0.098Lx0.079W 2.50mmx2.00mm 470nH
PDF
/
Buying Options
Total Price: USD $2.09
Unit Price: USD $2.09475
≥1 USD $2.09475
≥10 USD $1.71855
≥100 USD $1.66535
≥500 USD $1.6112
≥1000 USD $1.558
Inventory: 3001
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 1008 (2520 Metric)
Supplier Device Package 2510
Material - Core Iron Alloy
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-MAIA
Size / Dimension 0.098Lx0.079W 2.50mmx2.00mm
Tolerance ±30%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Molded
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 3.2A
Shielding Shielded
Current Rating 3.2A
Case Code (Metric) 2520
Case Code (Imperial) 1008
Inductance 470nH
Test Frequency 100kHz
DC Resistance (DCR) 48mOhm Max
Frequency - Self Resonant 170MHz
Inductance Frequency - Test 100kHz
Current - Saturation 5.5A
Dimensions
Height Seated (Max) 0.039 1.00mm
Length 2.4892mm
Width 2.0066mm
Compliance
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
