78438322022
RoHS
RoHS compliant
RoHS compliantPackage 1008 (2520 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-MAIA 1008 (2520Metric) 0.098Lx0.079W 2.50mmx2.00mm 2.2muH
PDF
/
Inventory: 9968
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Width 2.0066mm
Length 2.4892mm
Height Seated (Max) 0.031 0.80mm
Technical
Current - Saturation 2.2A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 60MHz
DC Resistance (DCR) 302mOhm Max
Test Frequency 100kHz
Inductance 2.2μH
Case Code (Imperial) 1008
Case Code (Metric) 2520
Current Rating 1.34A
Shielding Shielded
Current Rating (Amps) 1.34A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Molded
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±30%
Size / Dimension 0.098Lx0.079W 2.50mmx2.00mm
Series WE-MAIA
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Iron Alloy
Supplier Device Package 2508
Package / Case 1008 (2520 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
