744917239
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 390NH 170MA 4.7 OHM
PDF
/
Buying Options
Total Price: USD $0.58
Unit Price: USD $0.584046
≥1 USD $0.584046
≥10 USD $0.550987
≥100 USD $0.519803
≥500 USD $0.490383
≥1000 USD $0.46262
Inventory: 1204
Minimum: 1
-
+
Technical Details
Physical
Package / Case 0603 (1608 Metric)
Supplier Device Package 0603 (1608 Metric)
Material - Core Ceramic
Mounting Type Surface Mount
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-KI HC
Size / Dimension 0.067Lx0.043W 1.70mmx1.10mm
Tolerance ±2%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Current Rating (Amps) 170mA
Shielding Unshielded
Inductance 390nH
DC Resistance (DCR) 4.7Ohm Max
Frequency - Self Resonant 880MHz
Q @ Freq 25 @ 250MHz
Inductance Frequency - Test 100MHz
Dimensions
Height Seated (Max) 0.043 1.10mm
Compliance
RoHS Status ROHS3 Compliant
Supply Chain
Factory Lead Time 12 Weeks
