74479977147
RoHS
RoHS compliant
RoHS compliantPackage 0806 (2016 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PMMI 0806 (2016Metric) 0.079Lx0.063W 2.00mmx1.60mm 470nH
PDF
/
Buying Options
Total Price: USD $1.47
Unit Price: USD $1.473074
≥1 USD $1.473074
≥200 USD $0.588179
≥500 USD $0.568486
≥1000 USD $0.559295
Inventory: 4508
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 1.6002mm
Length 2.0066mm
Height Seated (Max) 0.024 0.60mm
Technical
RMS Current (Irms) 2.2A
Inductance Tolerance 20%
Current - Saturation 2.4A
Inductance Frequency - Test 1MHz
Frequency - Self Resonant 26MHz
DC Resistance (DCR) 65mOhm Max
Test Frequency 1MHz
Inductance 470nH
Case Code (Imperial) 0806
Case Code (Metric) 2016
Current Rating 2.2A
Shielding Shielded
Current Rating (Amps) 2.2A
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Multilayer
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.079Lx0.063W 2.00mmx1.60mm
Series WE-PMMI
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Package / Case 0806 (2016 Metric)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
