74479773133
RoHS
RoHS compliant
RoHS compliantPackage 0805 (2012 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PMI 0805 (2012Metric) 0.079Lx0.049W 2.00mmx1.25mm 330nH
PDF
/
Buying Options
Total Price: USD $0.37
Unit Price: USD $0.367334
≥1 USD $0.367334
≥10 USD $0.346546
≥100 USD $0.326929
≥500 USD $0.308423
≥1000 USD $0.290967
Inventory: 1382
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0805 (2012 Metric)
Supplier Device Package 0805 (2012 Metric)
Weight 32.006612mg
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-PMI
Size / Dimension 0.079Lx0.049W 2.00mmx1.25mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Multilayer
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Current Rating (Amps) 1.4A
Shielding Unshielded
Current Rating 1.4A
Case Code (Metric) 2012
Case Code (Imperial) 0805
Inductance 330nH
Test Frequency 1MHz
DC Resistance (DCR) 100mOhm
Max DC Current 1.4A
Frequency - Self Resonant 200MHz
Q @ Freq 8 @ 1MHz
Inductance Frequency - Test 1MHz
Current - Saturation 1.2A
Q Factor 8
Inductance Tolerance 20%
Dimensions
Height 500μm
Height Seated (Max) 0.024 0.60mm
Length 2.0066mm
Width 1.2446mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
