7447918
RoHS
RoHS compliant
RoHS compliantPackage 1206 (3216 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-MI 1206 (3216Metric) 0.126Lx0.063W 3.20mmx1.60mm 10muH
PDF
/
Buying Options
Total Price: USD $0.69
Unit Price: USD $0.6916
≥1 USD $0.6916
≥10 USD $0.5681
≥100 USD $0.55005
≥500 USD $0.532
≥1000 USD $0.5149
Inventory: 1200
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length 3.2mm
Height Seated (Max) 0.051 1.30mm
Height 1.1mm
Technical
Inductance Tolerance 10%
Inductance Frequency - Test 2MHz
Q @ Freq 50 @ 2MHz
Frequency - Self Resonant 26MHz
Max DC Current 25mA
DC Resistance (DCR) 600mOhm Max
Inductance 10μH
Depth 1.6mm
Shielding Unshielded
Current Rating (Amps) 25mA
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Type Multilayer
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension 0.126Lx0.063W 3.20mmx1.60mm
Series WE-MI
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Material - Core Nickel Zinc Ferrite (NiZn)
Supplier Device Package 1206
Package / Case 1206 (3216 Metric)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
