744786218A
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-MK 0603 (1608Metric) 0.063Lx0.031W 1.60mmx0.80mm 180nH
PDF
/
Inventory: 2751
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Supplier Device Package 0603 (1608 Metric)
Material - Core Ceramic
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series WE-MK
Size / Dimension 0.063Lx0.031W 1.60mmx0.80mm
Tolerance ±5%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Multilayer
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Current Rating (Amps) 200mA
Shielding Unshielded
Current Rating 200mA
Case Code (Metric) 1608
Case Code (Imperial) 0603
Inductance 180nH
Test Frequency 100MHz
DC Resistance (DCR) 1.9Ohm Max
Max DC Current 200mA
Frequency - Self Resonant 400MHz
Q @ Freq 8 @ 100MHz
Inductance Frequency - Test 100MHz
Inductance Tolerance 5%
Dimensions
Height Seated (Max) 0.037 0.95mm
Length 1.6002mm
Width 787.4μm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
