7447798241
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PDF Nonstandard 0.402Lx0.402W 10.20mmx10.20mm 24muH
PDF
/
Buying Options
Total Price: USD $22.76
Unit Price: USD $22.7563
≥1 USD $22.7563
≥10 USD $18.67225
≥100 USD $18.088
≥500 USD $17.5047
≥1000 USD $16.9214
Inventory: 4203
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 2
Material - Core Nickel Zinc Ferrite (NiZn)
Technical
Operating Temperature -40°C~150°C
Packaging Tape & Reel (TR)
Series WE-PDF
Size / Dimension 0.402Lx0.402W 10.20mmx10.20mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 4.5A
Shielding Shielded
Current Rating 4.5A
Lead Pitch 5.8mm
Inductance 24μH
Test Frequency 100kHz
DC Resistance (DCR) 39.5mOhm Max
Max DC Current 4A
Frequency - Self Resonant 16MHz
Inductance Frequency - Test 100kHz
Current - Saturation 3.25A
Inductance Tolerance 20%
RMS Current (Irms) 4.5A
Dimensions
Height 6.4mm
Height Seated (Max) 0.252 6.40mm
Length 10.2108mm
Width 10.2mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
