7447798111
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PDF Nonstandard 0.402Lx0.402W 10.20mmx10.20mm 11muH
PDF
/
Buying Options
Total Price: USD $1.61
Unit Price: USD $1.6112
≥1 USD $1.6112
≥10 USD $1.3224
≥100 USD $1.2806
≥500 USD $1.23975
≥1000 USD $1.19795
Inventory: 1145
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 2
Material - Core Nickel Zinc Ferrite (NiZn)
Technical
Operating Temperature -40°C~150°C
Packaging Tape & Reel (TR)
Series WE-PDF
Size / Dimension 0.402Lx0.402W 10.20mmx10.20mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 6.9A
Shielding Shielded
Depth 10.2mm
Current Rating 6.9A
Inductance 11μH
Test Frequency 100kHz
DC Resistance (DCR) 15.8mOhm Max
Max DC Current 5.8A
Frequency - Self Resonant 25MHz
Inductance Frequency - Test 100kHz
Current - Saturation 5.3A
Inductance Tolerance 20%
RMS Current (Irms) 6.9A
Dimensions
Height 6.4mm
Height Seated (Max) 0.252 6.40mm
Length 10.2mm
Width 10.2mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
