7447785122

Würth Elektronik
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-PD Robust Nonstandard 0.244Lx0.232W 6.20mmx5.90mm 22muH
PDF
/
Buying Options
Total Price: USD $0.78
Unit Price: USD $0.7752
≥1 USD $0.7752
≥10 USD $0.6365
≥100 USD $0.61655
≥500 USD $0.5966
≥1000 USD $0.57665
Inventory: 1130
Minimum: 1
-
+

Technical Details

Compliance

Ratings AEC-Q200
RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Width 6.2mm
Length 5.9mm
Height Seated (Max) 0.130 3.30mm
Height 3.3mm

Technical

RMS Current (Irms) 1.35A
Inductance Tolerance 25%
Current - Saturation 1.1A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 23MHz
Max DC Current 1.35A
DC Resistance (DCR) 250mOhm Max
Test Frequency 100kHz
Inductance 22μH
Current Rating 1.35A
Shielding Shielded
Current Rating (Amps) 1.35A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 250mOhm
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±25%
Size / Dimension 0.244Lx0.232W 6.20mmx5.90mm
Series WE-PD Robust
Packaging Cut Tape (CT)
Operating Temperature -40°C~125°C

Physical

Material - Core Ferrite
Weight 4.535924g
Number of Pins 2
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 70 Weeks
