744778003
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PD Nonstandard 0.287Lx0.287W 7.30mmx7.30mm 3.3muH
PDF
/
Buying Options
Total Price: USD $2.21
Unit Price: USD $2.2088
≥1 USD $2.2088
≥10 USD $1.9712
≥100 USD $1.8304
≥500 USD $1.76
≥1000 USD $1.6896
Inventory: 504
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Length 7.3mm
Height Seated (Max) 0.134 3.40mm
Height 3.2mm
Technical
Inductance Tolerance 20%
Current - Saturation 4.1A
Inductance Frequency - Test 1kHz
Frequency - Self Resonant 61MHz
Max DC Current 4.1A
DC Resistance (DCR) 32mOhm Max
Inductance 3.3μH
Depth 7.3mm
Shielding Shielded
Current Rating (Amps) 3.1A
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.287Lx0.287W 7.30mmx7.30mm
Series WE-PD
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
