744777930 image
Favorite
744777930 image
Favorite
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-PD Robust Nonstandard 0.287Lx0.287W 7.30mmx7.30mm 1mH
PDF
/
Buying Options
Total Price: USD $2.2
Unit Price: USD $2.198537
≥1 USD $2.198537
≥10 USD $2.074086
≥100 USD $1.956685
≥500 USD $1.845935
≥1000 USD $1.741451
Inventory: 8327
Minimum: 1
-
+

Technical Details

Compliance

Ratings AEC-Q200
RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Width 7.2898mm
Length 7.3mm
Height Seated (Max) 0.177 4.50mm
Height 1.5mm

Technical

Series Resistance 6Ohm
RMS Current (Irms) 200mA
Inductance Tolerance 20%
Current - Saturation 250mA
Inductance Frequency - Test 1kHz
Frequency - Self Resonant 2.3MHz
Max DC Current 200mA
DC Resistance (DCR) 6Ohm Max
Test Frequency 1kHz
Inductance 1mH
Current Rating 200mA
Depth 7.3mm
Shielding Shielded
Current Rating (Amps) 200mA
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 6Ohm
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.287Lx0.287W 7.30mmx7.30mm
Series WE-PD Robust
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Material - Core Ferrite
Supplier Device Package 7345
Number of Pins 2
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 16 Weeks
