7447779139
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PD Robust Nonstandard 0.287Lx0.287W 7.30mmx7.30mm 39muH
PDF
/
Buying Options
Total Price: USD $1.87
Unit Price: USD $1.874676
≥1 USD $1.874676
≥10 USD $1.768566
≥100 USD $1.668454
≥500 USD $1.574014
≥1000 USD $1.484918
Inventory: 1168
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 7.3mm
Length 7.3mm
Height Seated (Max) 0.177 4.50mm
Height 4.5mm
Technical
Series Resistance 230mOhm
RMS Current (Irms) 1.11A
Inductance Tolerance 20%
Current - Saturation 1.23A
Inductance Frequency - Test 1kHz
Frequency - Self Resonant 12MHz
Max DC Current 1.11A
DC Resistance (DCR) 230mOhm Max
Test Frequency 1kHz
Inductance 39μH
Lead Pitch 4mm
Current Rating 1.11A
Depth 7.3mm
Shielding Shielded
Current Rating (Amps) 1.11A
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 230mOhm
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.287Lx0.287W 7.30mmx7.30mm
Series WE-PD Robust
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Supplier Device Package 7345
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
