7447779115
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PD Robust Nonstandard 0.287Lx0.287W 7.30mmx7.30mm 15muH
PDF
/
Buying Options
Total Price: USD $2.08
Unit Price: USD $2.0768
≥1 USD $2.0768
≥10 USD $1.85328
≥100 USD $1.72128
≥500 USD $1.65528
≥1000 USD $1.5884
Inventory: 1086
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 7.2898mm
Length 7.3mm
Height Seated (Max) 0.177 4.50mm
Height 1.5mm
Technical
Series Resistance 81mOhm
RMS Current (Irms) 1.6A
Inductance Tolerance 20%
Current - Saturation 2.2A
Inductance Frequency - Test 1kHz
Frequency - Self Resonant 19.5MHz
Max DC Current 1.6A
DC Resistance (DCR) 81mOhm Max
Test Frequency 1kHz
Inductance 15μH
Current Rating 1.6A
Depth 7.3mm
Shielding Shielded
Current Rating (Amps) 1.6A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 81mOhm
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.287Lx0.287W 7.30mmx7.30mm
Series WE-PD Robust
Packaging Cut Tape (CT)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Weight 4.535924g
Supplier Device Package 7345
Number of Pins 2
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 70 Weeks
