744774212
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 120UH 490MA 930 MOHM
PDF
/
Buying Options
Total Price: USD $1.54
Unit Price: USD $1.543063
≥1 USD $1.543063
≥10 USD $1.455721
≥100 USD $1.373326
≥500 USD $1.295586
≥1000 USD $1.222249
Inventory: 1609
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.191 4.85mm
Technical
Inductance Tolerance 10%
Current - Saturation 630mA
Inductance Frequency - Test 10kHz
Frequency - Self Resonant 7MHz
DC Resistance (DCR) 930mOhm Max
Inductance 120μH
Shielding Unshielded
Current Rating (Amps) 490mA
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension 0.228Lx0.205W 5.80mmx5.20mm
Series WE-PD2
Packaging Cut Tape (CT)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
