744773039
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PD2 Nonstandard 0.177Lx0.157W 4.50mmx4.00mm 3.9muH
PDF
/
Buying Options
Total Price: USD $12.06
Unit Price: USD $12.06215
≥1 USD $12.06215
≥10 USD $9.8971
≥100 USD $9.58835
≥500 USD $9.27865
≥1000 USD $8.9699
Inventory: 1182
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Cut Tape (CT)
Series WE-PD2
Size / Dimension 0.177Lx0.157W 4.50mmx4.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Resistance 94mOhm
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 1.88A
Shielding Unshielded
Current Rating 1.88A
Inductance 3.9μH
Test Frequency 10kHz
DC Resistance (DCR) 94mOhm Max
Max DC Current 1.88A
Frequency - Self Resonant 50MHz
Inductance Frequency - Test 10kHz
Current - Saturation 2.57A
Inductance Tolerance 20%
RMS Current (Irms) 1.88A
Dimensions
Height 3.2mm
Height Seated (Max) 0.138 3.50mm
Length 4mm
Width 4.5mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
