744772330
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder (Open)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 33UH 2A 60 MOHM TH
PDF
/
Buying Options
Total Price: USD $0.79
Unit Price: USD $0.792077
≥1 USD $0.792077
≥10 USD $0.747239
≥100 USD $0.704952
≥500 USD $0.665044
≥1000 USD $0.627404
Inventory: 1089
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mounting Type Through Hole
Package / Case Radial, Vertical Cylinder (Open)
Number of Pins 2
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tray
Series WE-TI
Size / Dimension 0.307Dia 7.80mm
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Current Rating (Amps) 2A
Shielding Unshielded
Inductance 33μH
DC Resistance (DCR) 60mOhm Max
Frequency - Self Resonant 10.2MHz
Inductance Frequency - Test 1kHz
Current - Saturation 2.5A
Inductance Tolerance 10%
Dimensions
Height Seated (Max) 0.394 10.00mm
Compliance
RoHS Status ROHS3 Compliant
