744772047
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder (Open)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 4.7UH 4A 18 MOHM TH
PDF
/
Buying Options
Total Price: USD $0.86
Unit Price: USD $0.858743
≥1 USD $0.858743
≥10 USD $0.810136
≥100 USD $0.764283
≥500 USD $0.72102
≥1000 USD $0.680211
Inventory: 3040
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mounting Type Through Hole
Package / Case Radial, Vertical Cylinder (Open)
Number of Pins 2
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tray
Series WE-TI
Size / Dimension 0.307Dia 7.80mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Resistance 18mOhm
Current Rating (Amps) 4A
Shielding Unshielded
Inductance 4.7μH
DC Resistance (DCR) 18mOhm Max
Frequency - Self Resonant 43.1MHz
Inductance Frequency - Test 1kHz
Current - Saturation 5.4A
Inductance Tolerance 20%
Dimensions
Height Seated (Max) 0.394 10.00mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
