7447714331
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 330UH 710MA 750 MOHM
PDF
/
Buying Options
Total Price: USD $1.81
Unit Price: USD $1.81208
≥1 USD $1.81208
≥10 USD $1.709509
≥100 USD $1.612739
≥500 USD $1.521456
≥1000 USD $1.43533
Inventory: 979
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.197 5.00mm
Technical
Inductance Tolerance 20%
Current - Saturation 1A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 3.15MHz
DC Resistance (DCR) 750mOhm Max
Inductance 330μH
Shielding Shielded
Current Rating (Amps) 710mA
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.394Lx0.394W 10.00mmx10.00mm
Series WE-PD Performance
Packaging Cut Tape (CT)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
