744771004 image
Favorite
744771004 image
Favorite
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-PD Nonstandard 0.472Lx0.472W 12.00mmx12.00mm 4.7muH
PDF
/
Buying Options
Total Price: USD $0.75
Unit Price: USD $0.74765
≥1 USD $0.74765
≥10 USD $0.6137
≥100 USD $0.5947
≥500 USD $0.5757
≥1000 USD $0.5567
Inventory: 50819
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 16 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 2
Material - Core Ferrite

Technical

Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-PD
Size / Dimension 0.472Lx0.472W 12.00mmx12.00mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Resistance 11mOhm
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 8.25A
Shielding Shielded
Depth 12mm
Current Rating 8.25A
Inductance 4.7μH
Test Frequency 1kHz
DC Resistance (DCR) 11mOhm Max
Max DC Current 8.25A
Frequency - Self Resonant 35MHz
Inductance Frequency - Test 1kHz
Current - Saturation 8A
Inductance Tolerance 20%
RMS Current (Irms) 8.25A
Series Resistance 11mOhm

Dimensions

Height 6mm
Height Seated (Max) 0.236 6.00mm
Length 12mm
Width 12mm

Compliance

REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
