7447669012

Würth Elektronik
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-GFH Nonstandard 0.177Lx0.126W 4.50mmx3.20mm 1.2muH
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.330224
≥1 USD $0.330224
≥10 USD $0.311526
≥100 USD $0.293897
≥500 USD $0.277263
≥1000 USD $0.261573
Inventory: 3410
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Width 3.2004mm
Length 4.4958mm
Height Seated (Max) 0.134 3.40mm

Technical

Inductance Tolerance 10%
Inductance Frequency - Test 1.6MHz
Q @ Freq 30 @ 1.60MHz
Frequency - Self Resonant 182MHz
Max DC Current 1.8A
DC Resistance (DCR) 105mOhm Max
Test Frequency 1.6MHz
Inductance 1.2μH
Current Rating 1.8A
Shielding Unshielded
Current Rating (Amps) 1.8A
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension 0.177Lx0.126W 4.50mmx3.20mm
Series WE-GFH
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Material - Core Iron Powder
Supplier Device Package 4532
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 14 Weeks
