744765116A

Würth Elektronik
RoHS
RoHS RoHS compliant
Package 0402 (1005 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-KI 0402 (1005Metric) 0.039Lx0.022W 1.00mmx0.55mm 16nH
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.352144
≥1 USD $0.352144
≥10 USD $0.332207
≥100 USD $0.313407
≥500 USD $0.295666
≥1000 USD $0.278926
Inventory: 1944
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Width 550μm
Length 1mm
Height Seated (Max) 0.024 0.60mm
Height 500μm

Technical

Series Resistance 220mOhm
Inductance Tolerance 5%
Q Factor 24
Inductance Frequency - Test 250MHz
Q @ Freq 24 @ 250MHz
Frequency - Self Resonant 3.1GHz
Max DC Current 560mA
DC Resistance (DCR) 220mOhm Max
Test Frequency 250MHz
Inductance 16nH
Case Code (Imperial) 0402
Case Code (Metric) 1005
Frequency 250MHz
Current Rating 560mA
Depth 550μm
Shielding Unshielded
Current Rating (Amps) 560mA
Composition Ceramic, Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 220mOhm
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±5%
Size / Dimension 0.039Lx0.022W 1.00mmx0.55mm
Series WE-KI
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Material - Core Ceramic
Weight 20mg
Material Ceramic
Supplier Device Package 0402 (1005 Metric)
Number of Pins 2
Package / Case 0402 (1005 Metric)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 34 Weeks
