744761227C
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-KI 0603 (1608Metric) 0.065Lx0.045W 1.65mmx1.15mm 270nH
PDF
/
Buying Options
Total Price: USD $2.83
Unit Price: USD $2.8272
≥1 USD $2.8272
≥10 USD $2.3199
≥100 USD $2.2477
≥500 USD $2.17455
≥1000 USD $2.10235
Inventory: 84309
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0603 (1608 Metric)
Number of Pins 2
Supplier Device Package 0603 (1608 Metric)
Material Ceramic
Weight 2.012816mg
Material - Core Ceramic
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-KI
Size / Dimension 0.065Lx0.045W 1.65mmx1.15mm
Tolerance ±5%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Resistance 2.1Ohm
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Ceramic, Wirewound
Current Rating (Amps) 200mA
Shielding Unshielded
Depth 1.15mm
Current Rating 200mA
Frequency 100MHz
Case Code (Metric) 1608
Case Code (Imperial) 0603
Inductance 270nH
Test Frequency 100MHz
DC Resistance (DCR) 2.1Ohm Max
Max DC Current 200mA
Frequency - Self Resonant 822MHz
Q @ Freq 25 @ 100MHz
Inductance Frequency - Test 100MHz
Q Factor 25
Inductance Tolerance 5%
Series Resistance 2.1Ohm
Dimensions
Height 900μm
Height Seated (Max) 0.043 1.10mm
Length 1.65mm
Width 1.15mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
