744761033A

Würth Elektronik
RoHS
RoHS RoHS compliant
Package 0603 (1608 Metric)
Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-KI 0603 (1608Metric) 0.063Lx0.041W 1.60mmx1.05mm 3.3nH
PDF
/
Buying Options
Total Price: USD $3.36
Unit Price: USD $3.35825
≥1 USD $3.35825
≥10 USD $2.75595
≥100 USD $2.6695
≥500 USD $2.58305
≥1000 USD $2.49755
Inventory: 1164
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Width 1.05mm
Length 1.6mm
Height Seated (Max) 0.049 1.25mm
Height 1.05mm

Technical

Series Resistance 60mOhm
Q Factor 22
Inductance Frequency - Test 250MHz
Q @ Freq 22 @ 250MHz
Frequency - Self Resonant 5.8GHz
Max DC Current 700mA
DC Resistance (DCR) 60mOhm Max
Test Frequency 250MHz
Inductance 3.3nH
Case Code (Imperial) 0603
Case Code (Metric) 1608
Frequency 250MHz
Current Rating 700mA
Depth 1.05mm
Shielding Unshielded
Current Rating (Amps) 700mA
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 60mOhm
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±0.2nH
Size / Dimension 0.063Lx0.041W 1.60mmx1.05mm
Series WE-KI
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Material - Core Ceramic
Weight 30mg
Material Ceramic
Supplier Device Package 0603
Number of Pins 2
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 11 Weeks
