7447604C
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-KI Nonstandard 0.090Lx0.067W 2.29mmx1.70mm 680nH
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.352
≥1 USD $0.352
≥10 USD $0.3344
≥100 USD $0.3124
≥500 USD $0.28952
≥1000 USD $0.26576
≥3000 USD $0.24288
Inventory: 1121
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 2
Supplier Device Package 0805
Material Ceramic
Weight 32.006612mg
Material - Core Ceramic
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-KI
Size / Dimension 0.090Lx0.067W 2.29mmx1.70mm
Tolerance ±5%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Resistance 2.7Ohm
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Ceramic, Wirewound
Current Rating (Amps) 190mA
Shielding Unshielded
Depth 1.7mm
Current Rating 190mA
Frequency 50MHz
Case Code (Metric) 2012
Case Code (Imperial) 0805
Inductance 680nH
Test Frequency 50MHz
DC Resistance (DCR) 2.8Ohm Max
Max DC Current 190mA
Frequency - Self Resonant 188MHz
Q @ Freq 23 @ 50MHz
Inductance Frequency - Test 25MHz
Q Factor 23
Inductance Tolerance 5%
Series Resistance 2.8Ohm
Dimensions
Height 1.28mm
Height Seated (Max) 0.058 1.48mm
Length 2.28mm
Width 1.7mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
