7447471102
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-TIS Radial Vertical Cylinder 0.433Dia 11.00mm 1mH
PDF
/
Buying Options
Total Price: USD $2.02
Unit Price: USD $2.016772
≥1 USD $2.016772
≥10 USD $1.902617
≥100 USD $1.794926
≥500 USD $1.693327
≥1000 USD $1.597479
Inventory: 1565
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 11mm
Length 11.5mm
Height Seated (Max) 0.453 11.50mm
Diameter 11mm
Technical
Series Resistance 1.2Ohm
RMS Current (Irms) 600mA
Inductance Tolerance 20%
Current - Saturation 400mA
Inductance Frequency - Test 1kHz
Frequency - Self Resonant 1.1MHz
Max DC Current 600mA
DC Resistance (DCR) 1.5Ohm Max
Test Frequency 1kHz
Inductance 1mH
Lead Pitch 5mm
Frequency 1.1MHz
Current Rating 600mA
Shielding Shielded
Current Rating (Amps) 600mA
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Termination Radial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Shielded
Tolerance ±20%
Size / Dimension 0.433Dia 11.00mm
Series WE-TIS
Packaging Tray
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Number of Pins 2
Package / Case Radial, Vertical Cylinder
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 22 Weeks
