7447462471
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-TI Radial Vertical Cylinder 0.236Dia 6.00mm 470muH
PDF
/
Buying Options
Total Price: USD $0.69
Unit Price: USD $0.693634
≥1 USD $0.693634
≥10 USD $0.654375
≥100 USD $0.617335
≥500 USD $0.582389
≥1000 USD $0.549418
Inventory: 1217
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Vertical Cylinder
Number of Pins 2
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Bulk
Series WE-TI
Size / Dimension 0.236Dia 6.00mm
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Radial
Type Wirewound
Resistance 2.4Ohm
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 350mA
Shielding Unshielded
Current Rating 350mA
Frequency 2.9MHz
Lead Pitch 2.5mm
Inductance 470μH
Test Frequency 1kHz
DC Resistance (DCR) 2.4Ohm Max
Max DC Current 350mA
Frequency - Self Resonant 2.9MHz
Inductance Frequency - Test 1kHz
Current - Saturation 400mA
Inductance Tolerance 10%
RMS Current (Irms) 350mA
Dimensions
Diameter 6mm
Height 8.5mm
Height Seated (Max) 0.335 8.50mm
Length 8.5mm
Width 6mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
