7447462330

Würth Elektronik
RoHS
RoHS RoHS compliant
Package Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-TI Radial Vertical Cylinder 0.236Dia 6.00mm 33muH
PDF
/
Buying Options
Total Price: USD $0.82
Unit Price: USD $0.819436
≥1 USD $0.819436
≥10 USD $0.773054
≥100 USD $0.7293
≥500 USD $0.68802
≥1000 USD $0.649066
Inventory: 1173
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 22 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case Radial, Vertical Cylinder
Number of Pins 2
Material - Core Ferrite

Technical

Operating Temperature -40°C~125°C
Packaging Bulk
Series WE-TI
Size / Dimension 0.236Dia 6.00mm
Tolerance ±20%
Part Status Active
RMS Current (Irms) 1.4A
Inductance Tolerance 20%
Current - Saturation 1.4A
Inductance Frequency - Test 1kHz
Frequency - Self Resonant 14MHz
Max DC Current 1.4A
DC Resistance (DCR) 220mOhm Max
Test Frequency 1kHz
Inductance 33μH
Lead Pitch 2.5mm
Frequency 14MHz
Current Rating 1.4A
Shielding Unshielded
Current Rating (Amps) 1.4A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 220mOhm
Type Wirewound
Termination Radial
Moisture Sensitivity Level (MSL) 1 (Unlimited)

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Width 6mm
Length 8.5mm
Height Seated (Max) 0.335 8.50mm
Height 8.5mm
Diameter 6mm
