RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description ROHS3Compliant Wirewound Active Cut Tape Fixed Inductor -40C~125C 4.6MHz 293mOhm Max 150muH
PDF
/
Buying Options
Total Price: USD $3.29
Unit Price: USD $3.2912
≥1 USD $3.2912
≥10 USD $2.47544
≥100 USD $2.17096
≥500 USD $1.8172
Inventory: 739
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Height Seated (Max) 0.300 7.62mm

Technical

RMS Current (Irms) 1.3A
Inductance Tolerance 20%
Current - Saturation 2.1A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 4.6MHz
DC Resistance (DCR) 293mOhm Max
Inductance 150μH
Shielding Shielded
Current Rating (Amps) 1.3A
Resistance 209mOhm
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.730Lx0.600W 18.54mmx15.24mm
Series WE-PD3
Packaging Cut Tape
Operating Temperature -40°C~125°C

Physical

Material - Core Ferrite
Number of Pins 2
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 18 Weeks
