7445304
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Wirewound Active Cut Tape Fixed Inductor -40C~125C 44MHz 78mOhm Max 4.7muH
PDF
/
Buying Options
Total Price: USD $2.57
Unit Price: USD $2.5696
≥1 USD $2.5696
≥10 USD $1.9272
≥100 USD $1.68344
≥500 USD $1.41504
≥1000 USD $1.35432
Inventory: 1887
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Number of Pins 2
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Cut Tape
Series WE-PD3
Size / Dimension 0.500Lx0.398W 12.70mmx10.10mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Wirewound
Resistance 65mOhm
Current Rating (Amps) 1.9A
Shielding Shielded
Current Rating 1.9A
Inductance 4.7μH
DC Resistance (DCR) 78mOhm Max
Frequency - Self Resonant 44MHz
Inductance Frequency - Test 100kHz
Current - Saturation 3.6A
Inductance Tolerance 20%
RMS Current (Irms) 1.9A
Series Resistance 65mOhm
Dimensions
Height Seated (Max) 0.118 3.00mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Alternative Model
