74437529203330
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-HCF ROUND SMD HIGH CURRENT IN
PDF
/
Buying Options
Total Price: USD $6.91
Unit Price: USD $6.906082
≥1 USD $6.906082
≥10 USD $6.515173
≥100 USD $6.14639
≥500 USD $5.798479
≥1000 USD $5.470268
Inventory: 4358
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.807 20.50mm
Technical
Inductance Tolerance 20%
Current - Saturation 15.4A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 7.1MHz
DC Resistance (DCR) 6.9mOhm
Inductance 33μH
Shielding Shielded
Current Rating (Amps) 20.2A
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 1.102Lx0.984W 28.00mmx25.00mm
Series WE-HCF
Packaging Tray
Operating Temperature -40°C~125°C
Physical
Material - Core Manganese Zinc Ferrite (MnZn)
Supplier Device Package 2920
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 17 Weeks
